Technical manual summary
Tech sheet W10806847B describes service diagnostic entry, user-interface checks and a loads test. It covers the motor, heater, water valve where fitted, door switch and moisture-sensing responses. The control-panel illustrations and appliance configuration should be matched before using the test sequence.
Its code table separates F1E1, a Cycle Control Unit (CCU) problem, from sensor faults. F3E1 and F3E2 identify open and shorted exhaust-thermistor conditions respectively; F3E6 and F3E7 concern open and shorted moisture-sensor conditions. The sheet directs technicians to the corresponding power, connection and sensor tests.
Temperature sensing, airflow and electrostatic protection are important subjects in this sheet. The document includes thermistor checks and precautions for handling the control electronics. Internal measurements and component tests belong to service work, while the complete model and wiring information remain essential to selecting the correct procedure.
W10806847B was recovered from this model page. Exact WED92HEFW1 revision applicability remains unconfirmed; match the document number, control design and wiring against the appliance’s supplied sheet.
Document references
This page uses the same unchanged W10806847B document as several other recovered pages. Shared file bytes do not independently prove each model association. The printed document number is W10806847B.
For owner instructions, use Whirlpool’s manual lookup with the complete model from the appliance label.
